Vaccine Van(7-meter model)

Function Configuration Online Service Service

Vaccine Van(7-meter model)

Medical Vehicle

Download the product brochure

This model is specially developed for the "vaccination" stage, and it can go into communities and schools, etc. to provide convenient immunization services.

High vaccination efficiency：Vaccinate 20-30 people per hour.

Onboard smart vaccination management system：Auxiliary vaccination table enables fast and accurate vaccination. Real-time uploading of vaccination records, fully traceable during the whole process.

Flexible switch between different power sources：Easy switch between power grid and power generator to ensure vaccine safety.

Cold-chain storage：Controlled by microcomputer with temperature display and alarm system. Keep vaccines within the right temperature range for up to seven days without electricity

Specification

Basic parameters

ModelVACCINE VAN 7-meter mode
Vaccine refrigeratorVaccine refrigerator capacity is 37.5L; Cass A frost-proof; temperature in the refrigerator is 2℃-8℃; ambient temperature of operation is 5℃-43℃
Silent diesel generatorOnboard equipment is powered by power grid
Onboard air conditioner1 set of 1.5P top mounted air conditioner and 1 set of 1.5p wall mounted air conditioner

Body

Vaccination stationThe vaccination records of the whole process are fully traceable and uploaded in real time; 8 automatic drawers can store corresponding vaccines; drawer capacity is 8L each, 8 drawers can store up to 200 doses of vaccines.The temperature in the box is 2-8℃; integrated cold chain monitoring can achieve real-time uploading of cold chain data; drawer is equipped with magnetic locks protected with instructions; emergency keys can open all drawers; with prevention and vaccination function

*Special statement:

Due to the conversion period between vehicle update and network display, the graphics and text parameters of the page may be different from the actual vehicle. The graphics and text content of the page are not used as the basis for actual vehicle booking. The actual vehicle configuration determined by the specific model and technical parameters shall prevail. Prospective buyers shall contact Yutong sales staff to confirm and Yutong reserves the right to change the picture parameters and the final interpretation.
